Model No : RE-109
Rudra power drive semi battery operated stacker with 1000 kg capacity is ideal, simple & effective solution for stacking & vertical storage spacing warehouse and used in widest range of applications.
Features :
- Floating frame structure with advance mounting type
- Detachable design with high accuracy & better hardness
- Better vision for operator
- Better protection to pallet load
- Easier maintenance
- High accuracy
- Wider rider platform for more space of standing
- Side slidable battery box
| Model No. | RE-109-1 TON – 1.6 MTR | RE-109-1 TON -2 MTR | RE-109-1 TON-3 MTR |
| Capacity (KG) | 1000 | 1000 | 1000 |
| Lifting Height (MM) | 1600 | 2000 | 3000 |
| Mast Type | 2150 | Depend on height | Depend on height |
| Lowered Height of Fork (MM) | 90 | 90 | 90 |
| Fork Outer Distance (MM) | 550 | 550 | 550 |
| Fork Length (MM) | 1150 | 1150 | 1150 |
| Overall Width (MM) | 760 | 760 | 760 |
| Turning Radius (MM) | 1600 | 1600 | 1600 |
| Wheel (Drive / Load) Type | PU | PU | PU |
| Size of Steering Wheel (MM) | ø180*50 | ø180*50 | ø180*50 |
| Size of Loading Wheel (MM) | ø80*50 | ø80*50 | ø80*50 |
